Tip and Bit Detector Controller
Tip and Bit Detector Controller is an electronic control device used for automatic and high-speed multi-drill or tapping machines to detect broken drill bits, broken taps and missing tool tips during production. UMA Industries supplies tip detector controllers, bit detector controllers, broken drill detection systems, tap breakage detection controllers, infrared sensor based tool checking devices and customized industrial automation instruments for drilling, tapping, machining and special-purpose machines.
This Tip and Bit Detector Controller works with a red rays infrared sensor to check the presence of a drill bit or tap at the set checking position. During machine operation, when the drill or tap stays for a moment at the selected position, the sensor checks the tool condition. If the drill bit or tap is broken, missing or not detected properly, the controller raises an alarm and stops the machine to prevent further damage.
The device is useful for automatic drilling machines, high-speed multi-spindle drill machines, tapping machines, SPM machines, transfer lines and production machines where broken tool detection is important for quality, safety and machine protection.
Technical Specifications of Tip and Bit Detector Controller
- Product Name: Tip and Bit Detector Controller
- Device Type: Electronic broken tool detection controller
- Application: Drill bit detection and tap detection
- Suitable Machine: Automatic drill machine, multi-drill machine, high-speed tapping machine and SPM machine
- Sensor Type: Red rays infrared sensor
- Detection Method: Tool presence checking at selected position
- Checking Condition: Sensor checks when drill or tap stays for a moment at set position
- Fault Detection: Broken drill, broken tap, missing tip or tool not detected
- Output Action: Alarm and machine stop signal
- Control Function: Machine interlock after tool breakage detection
- Installation: Machine control panel or special-purpose machine panel
- Customization: Sensor logic, timing, alarm output and machine-stop logic can be customized as per machine requirement
What is Tip and Bit Detector Controller?
Tip and Bit Detector Controller is a machine protection and tool detection device used to identify broken drill bits or broken taps in automatic machines. In high-speed drilling or tapping operations, a broken tool can damage the job, spoil production, damage fixture, damage spindle or create repeated defective parts.
The controller checks the drill or tap using a red infrared sensor at a selected checking position. If the sensor does not detect the tool properly, the controller activates an alarm and sends a stop signal to the machine control circuit. This helps the operator identify tool breakage quickly and prevents the machine from continuing production with a broken tool.
How Tip and Bit Detector Controller Works
- The red rays infrared sensor is installed near the drill or tap checking position.
- The machine cycle brings the drill bit or tap to the checking point.
- The drill or tap stays for a short moment at the set position.
- The sensor checks whether the tool tip or bit is present.
- The controller reads the sensor signal.
- If the tool is detected correctly, the machine continues operation.
- If the tool is broken, missing or not detected, the controller raises an alarm.
- The controller gives machine-stop output to prevent further production damage.
Red Rays Infrared Sensor Based Detection
The Tip and Bit Detector Controller uses a red rays infrared sensor for checking drill bit or tap presence. The sensor is positioned so that it can detect the tool at the selected reference point. When the tool comes to the detection position, the sensor confirms whether the drill or tap is present.
This infrared detection method is useful because it is non-contact, fast and suitable for repetitive automatic machine cycles. Correct sensor positioning, stable mounting and proper setting are important for reliable broken tool detection.
Applications of Tip and Bit Detector Controller
Automatic Drilling Machines
Automatic drilling machines use tip and bit detector controllers to check drill bit presence during production. If the drill breaks, the controller raises alarm and stops the machine.
High-Speed Multi-Drill Machines
High-speed multi-spindle drilling machines use broken drill detection systems to avoid repeated defective parts and damage to fixtures or workpieces.
Tapping Machines
Tapping machines use tap detector controllers to detect broken taps. A broken tap can damage threaded holes, job material and machine tooling, so early detection is important.
SPM Machines
Special-purpose machines use infrared tool detection controllers for automatic drill checking, tap checking and process interlocking.
Transfer Line Machines
Production transfer lines use tool detection devices to stop the process immediately when a drill or tap breaks at one station.
Automobile Component Manufacturing
Automobile component manufacturers use drill and tap detection for brackets, housings, castings, sheet metal parts, machined parts and assembly components.
Engineering and Fabrication Units
Engineering units use tip detector systems in repetitive drilling and tapping machines to reduce rejection and tool-related downtime.
Fixture-Based Production Machines
Fixture-based production machines use tool detection devices to confirm tool presence before the next operation starts.
Why Choose Our Tip and Bit Detector Controller?
- Designed for automatic drill and tapping machines
- Uses red rays infrared sensor for tool checking
- Detects broken drill bit and broken tap
- Raises alarm when tool is not detected
- Stops machine to prevent further damage
- Suitable for high-speed multi-drill machines
- Useful for special-purpose machine automation
- Sensor position setting during tool stay condition
- Custom timing and machine interlock logic available
- Suitable for production quality and machine protection
Broken Drill Detection
During drilling operation, the drill bit may break due to material hardness, wrong feed, tool wear, improper coolant, chip jamming or high production load. If the broken drill is not detected, the machine may continue operation and produce defective parts.
The Tip and Bit Detector Controller checks the drill bit at a selected point. If the bit is missing or shorter due to breakage, the infrared sensor does not detect the expected tool position, and the controller stops the machine with alarm indication.
Broken Tap Detection
Tap breakage is a common issue in automatic tapping machines. A broken tap may remain inside the job and cause rejection, rework or fixture damage. In multi-station machines, undetected tap breakage can create repeated defective parts.
The controller checks the tap at the set detection position. If the tap is broken or missing, the device raises an alarm and stops the machine before more parts are damaged.
Machine Stop and Alarm Function
The controller provides alarm and machine-stop output when tool breakage is detected. This output can be connected to the machine control panel, relay logic, PLC input, alarm buzzer, tower lamp or machine interlock circuit.
- Alarm Output: Indicates broken drill, broken tap or missing tool condition.
- Machine Stop Output: Stops machine cycle to avoid further damage.
- Operator Indication: Alerts operator for tool replacement and checking.
- Interlock Logic: Prevents next cycle until the fault is cleared as per machine design.
Setting Position During Tool Stay Moment
The detection point is set when the drill or tap stays for a moment at the required position. This moment allows the red rays infrared sensor to check the tool condition reliably. The sensor should be adjusted so that the tool tip or bit is detected correctly during this short checking time.
Correct position setting is important. If the sensor is too far, too close, misaligned or affected by vibration, detection may become unstable. Proper mechanical bracket, sensor alignment and stable machine timing improve reliability.
Installation Instructions
- Install the controller inside a clean and protected electrical control panel.
- Mount the red rays infrared sensor near the tool checking position.
- Ensure that the drill or tap stays momentarily at the sensor checking point.
- Adjust the sensor so that it detects the complete tool correctly.
- Keep the sensor bracket rigid and vibration-free.
- Protect the sensor from coolant splash, oil, metal chips and dust.
- Keep sensor wiring away from motor, solenoid, contactor and VFD wiring.
- Connect alarm and machine-stop outputs according to machine control-panel logic.
- Test the system with a good drill or tap before production.
- Test broken-tool condition carefully during commissioning.
Operating Instructions
- Switch ON the machine and controller.
- Check sensor alignment with a good drill or tap.
- Set the checking position where the tool stays for a moment.
- Run the machine in trial mode and verify tool detection.
- Confirm that the machine continues when the tool is detected correctly.
- Simulate missing tool or broken tool condition during safe testing.
- Confirm that alarm activates and machine stops.
- After tool replacement, reset the machine according to operating procedure.
- Start production only after successful detection check.
Maintenance Instructions
- Clean the infrared sensor lens regularly.
- Check sensor mounting bracket for looseness.
- Inspect sensor cable for cut, bend or damage.
- Check machine vibration near the sensor mounting point.
- Verify alarm and machine-stop output during preventive maintenance.
- Check sensor detection with a good drill or tap after tool change.
- Remove metal chips, oil, coolant and dust from sensor area.
- Do not bypass the broken tool detection system during production.
Precautions for Tip and Bit Detector Controller
- Do not install the sensor where coolant continuously falls on the lens.
- Do not allow metal chips to block the sensor beam.
- Do not run sensor cable with power wiring.
- Do not keep the sensor bracket loose or vibrating.
- Do not bypass machine-stop output during production.
- Do not change sensor position without checking detection accuracy.
- Do not operate the machine after alarm without checking drill or tap condition.
- Use proper guarding and machine-safety interlock as per machine requirement.
Common Fault Conditions
- Broken drill bit
- Broken tap
- Missing drill or tap
- Sensor misalignment
- Sensor lens blocked by coolant or chips
- Loose sensor bracket
- Tool not staying at correct checking position
- Incorrect machine timing
- Sensor cable damage
- Machine vibration causing unstable detection
Industries Using Tip and Bit Detector Controller
- Automobile component manufacturers
- Sheet metal component manufacturers
- Machining industries
- SPM machine manufacturers
- High-speed drilling machine users
- Tapping machine users
- Transfer line manufacturers
- Engineering workshops
- Fixture and jig manufacturers
- Mass production component manufacturers
- Control-panel manufacturers
- Industrial automation companies
Related Products and Machine Control Devices
- Electronic Control Devices – Customized embedded control systems for industrial machines.
- Machine Monitoring Systems – Production counting, runtime and machine-status monitoring.
- Industrial Control Panels – Customized panels for machine control and automation.
- Relay Output Controllers – Digital instruments with relay output for industrial control.
- RS485 Modbus Instruments – Digital communication instruments for PLC and SCADA systems.
7 Powerful Benefits of Tip and Bit Detector Controller
- Detects broken drill and broken tap
- Uses red rays infrared sensor for tool checking
- Raises alarm during tool breakage condition
- Stops machine to prevent further damage
- Suitable for automatic and high-speed machines
- Useful for multi-drill and tapping applications
- Improves production quality and reduces rejection
FAQs About Tip and Bit Detector Controller
What is Tip and Bit Detector Controller?
Tip and Bit Detector Controller is an electronic device used to detect broken drill bits or broken taps in automatic drilling and tapping machines.
Which sensor is used in this device?
The device uses a red rays infrared sensor for detecting the presence of the drill bit or tap.
How does it detect a broken drill?
The sensor checks the drill at a selected position. If the drill bit is broken or missing, the controller raises an alarm and stops the machine.
Can it detect a broken tap?
Yes, the controller can detect broken tap condition when the tap is checked at the set position using the infrared sensor.
Where is the sensor position set?
The sensor is set at the position where the drill or tap stays for a moment during the machine cycle.
What happens when the tool is broken?
The controller raises an alarm and gives machine-stop output to prevent further production damage.
Can it be used in high-speed multi-drill machines?
Yes, it is suitable for automatic and high-speed multi-drill machines where tool breakage detection is required.
Can it be used in tapping machines?
Yes, it is suitable for automatic tapping machines and SPM tapping applications.
Can the logic be customized?
Yes, sensor timing, alarm output, stop output and machine interlock logic can be customized according to machine requirement.
Can it be connected to PLC?
Yes, the alarm or detection output can be connected to PLC input or machine control panel according to wiring design.
Does it reduce rejection?
Yes, it helps reduce rejection by stopping the machine when a drill or tap breaks during production.
Do you supply throughout India?
Yes, UMA Industries supplies Tip and Bit Detector Controller, broken tool detection devices, electronic control systems and machine automation instruments throughout India.
